Polycom RMX 2000Hardware GuideVersion 1.1

Chapter 1- Hardware Description1-4• In a single rack installation, stabilizers should be attached to the rack.• In multiple rack installations, the ra

Polycom RMX 2000 Hardware Guide1-5RMX 2000 ComponentsOn the RMX 2000 modules are located on both the front and rear of the MCU as listed in Table 1-2,

Chapter 1- Hardware Description1-6Table 1-2 Polycom RMX 2000 Component DescriptionComponent DescriptionCPU (CNTL) ModuleThe CPU Module controls and m

Polycom RMX 2000 Hardware Guide1-7RMX 2000 Rear PanelThe RMX 2000 rear panel contains the RTM IP board. In addition, the rear panel houses the main po

Chapter 1- Hardware Description1-8The following items appear on the RMX 2000 rear panel:Table 1-3 RMX 2000 Rear Panel - RTM IP Component DescriptionF

Polycom RMX 2000 Hardware Guide1-9Cables Connected to the RTM IP BoardAll external connectors are located on the rear panel.Figure 1-3 RMX 2000 Rear P

Chapter 1- Hardware Description1-10RMX 2000 LEDsThe RMX includes LEDs located on the front panel and rear panel. In the front panel, the LEDs reflect

Polycom RMX 2000 Hardware Guide1-11RMX 2000 Rear Panel LEDsThe following items appear on the RMX 2000 rear panel:MPM ERR Red ON - Major error on board

Chapter 1- Hardware Description1-12SLOT (1-4) LEDsLNK (1-4) Green Lit with active network connection, flickers with Packet activity.1Gb (1-4) Amber Li

Polycom RMX 2000 Hardware Guide1-13Component ReplacementThe RMX 2000 is designed with ease of maintenance in mind. Most components are swappable and a

Copyright © 2007 Polycom, Inc.All Rights ReservedCatalog No. DOC2160A Version 1.1Proprietary and ConfidentialThe information contained herein is the

Chapter 1- Hardware Description1-14Replacing the CPU (CNTL) ModuleThe CPU module is the management system of the RMX 2000. Use the following procedure

Polycom RMX 2000 Hardware Guide1-15Replacing a Functional MPM ModuleUse the following procedure to replace a faulty MPM Module types F or H:1 Ensure t

Chapter 1- Hardware Description1-16Replacing the Power Supply DrawerA single supply unit powers the RMX 2000. Use the following procedure to replace a

Polycom RMX 2000 Hardware Guide1-17Replacing the Fan DrawerThree fans are mounted in the Fan Drawer, where the airflow is from right to left. Should o

Chapter 1- Hardware Description1-18Replacing the RTM IP BoardThe RTM IP board on the rear of the RMX 2000 provides connectivity to all the MCU modules

Regulatory NoticesUnited States Federal Communication Commission (FCC)Part 15: Class A Statement. This equipment has been tested and found to comply w

Chinese Communication CertificateRegulatory Notices

Polycom RMX 2000 Hardware GuideiTable of ContentsHardware Description . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1Main Features ...

Table of Contentsii

1-11Hardware DescriptionThis Hardware Guide provides information on the RMX 2000 and its components. This system utilizes a modular “universal slot” p

Chapter 1- Hardware Description1-2RMX 2000 SpecificationsTable 1-1 Polycom RMX 2000 SpecificationsPhysicalHeight 3U (13.28 cm.)Width 19” (48.26 cm.)D

Polycom RMX 2000 Hardware Guide1-3Site RequirementsThis section describes the requirements your site must meet for safe installation and operation of
